| Measuring Principle : Ultrasonic (Gas) | Application : Natural and process gas in the chemical, oil and gas industries |
| Size Range : DN25-300 (1"-12") | Brand : Endress+Hauser |
File Download
| MEASURING PRINCIPLE |
| Ultrasonic time-of-flight flowmeter for gas. Direct measurement of flow, pressure and temperature, with real-time pressure- and temperature-compensated values. The measuring principle is unaffected by gas composition. Remote transmitter version. |
| APPLICATION |
| Accurate measurement of natural and process gas in the chemical as well as oil and gas industries, even with wet gas and changing gas properties and compositions. |
| SIZE RANGE |
| DN Sizes : DN 25 to DN 300 (1" to 12") |
| PROCESS CONDITIONS |
| Temperature Range : -50°C to +150°C (-58°F to +302°F) |
| Temperature Range (with integrated pressure cell) : -50°C to +100°C (-58°F to +212°F) |
| Pressure Range : 0.7 to 101 bar a (10.15 to 1464.88 psi a) |
| WETTED MATERIALS |
| Measuring Tube : 1.4408/1.4409 (CF3M) |
| Transducer : Stainless steel 1.4404 (316/316L), titanium Grade 2 |
| Transmitter Housing : Aluminium AlSi10Mg (coated), cast stainless steel 1.4409 (CF3M) or polycarbonate |
| KEY FEATURES |
| • Maximum accuracy 0.5 % (volume flow ±1.0 % o.r. at 3 to 40 m/s, ±0.5 % o.r. with optional calibration) |
| • Gas measuring range 0.3 to 40 m/s |
| • Sensor design insensitive to condensate, reliable even with humid or wet gas |
| • User-definable gas mixtures for demanding measuring tasks |
| • Multivariable, no pressure loss: volume flow (also corrected), mass flow, flow velocity, speed of sound, pressure, temperature, density, dynamic viscosity, energy flow, Wobbe index, methane fraction, calorific value and molar mass |
| • Pressure-rated sensor housing with rupture disc limits safety risks |
| • Remote transmitter with up to 4 I/Os, backlit touch display with WLAN access |
| • Integrated verification with Heartbeat Technology |
| Brand : Endress+Hauser |
| Product Family : Proline Prosonic Flow |
